Hello
Can I convert a heng long 1/16 6.0S. smoking unit to run off a Taigen V3?
Thanks in advance
Frank
Smoke unit
Forum rules
If your question is electronics related please post it in one of the relevant boards here: viewforum.php?f=31
If your question is electronics related please post it in one of the relevant boards here: viewforum.php?f=31
Smoke unit
- Attachments
-
- Captureggggggggggggggg.PNG (157.24 KiB) Viewed 566 times
-
Afrikakorps
- Corporal
- Posts: 250
- Joined: Sun Jun 14, 2015 1:40 am
- Location: Australia
Re: Smoke unit
Hi Topper,Topper wrote:Hello
Can I convert a heng long 1/16 6.0S. smoking unit to run off a Taigen V3?
Thanks in advance
Frank
Yes you can but you will need to join the fan motor wires to the heater element wires. That way you will only have one 2 pin plug to fit into the Taigen board. Same position as the Taigen smoker. The fan and the heater will both work at the same time, so if it blows too fast, a small resistor inline with the fan may be needed.
Cheers Steve
Sent from my iPhone using Tapatalk
Panzer III G
Sherman M4A3 (105)
T-34/76 (1942)
Panzer IV Wirbelwind
Sturmtiger
KV-2
M26 Pershing
T-34/76 (1943)
KV-1
M3 Lee
Ferdinand / Elephant
M16 Half-track
Panther G
M4a1 (75mm)
M41 Walker Bulldog
JS-2
M4a3e8 (76mm)
Japanese Type94
FT-17
Tiger 1
Sherman M4A3 (105)
T-34/76 (1942)
Panzer IV Wirbelwind
Sturmtiger
KV-2
M26 Pershing
T-34/76 (1943)
KV-1
M3 Lee
Ferdinand / Elephant
M16 Half-track
Panther G
M4a1 (75mm)
M41 Walker Bulldog
JS-2
M4a3e8 (76mm)
Japanese Type94
FT-17
Tiger 1
Re: Smoke unit
Thanks Steve
