New project Krupp Raumer S

[midlife306]

Hi all,
I've been looking for a decent sized project to 3d print, to be honest I feel lost now that my 1/16 LCM3 is all but finished.
I managed to find a 3d model of a Krupp Raumer S. Its a big bugger, so it should take a week or two...
The model I found is supposed to be 1/100, after checking the o/d of the wheels ive had to scale them up by 629% to get them the correct diameter for 1/16 scale. The wheels were 2.7m diameter, gulp
I'll post a pic up shortly of a wheel at size on my Slicer desktop.
Here is a pic to whet your appetites.
Cheers
Wayne

[midlife306]

As promised, here’s a 2.7m wheel at 1/16 in my Slic3r program. The bed size you can see is 220 x 220mm

Cheers
Wayne


Sent from my iPhone using Tapatalk

[midlife306]

A few days in & I’ve completed printing the front half, it measures 540mm long x 165mm wide at the cabin. Luckily the rear half is a carbon copy of the front so my printer is off running proven g code
I can’t help thinking that strategically this thing would have been an awesome piece of kit for breaking through defences & there’s loads of room inside it, you’d think it would carry at least some form of weapon......
The biggest headache is going to be the articulation joint & making it steerable, I’ve been giving it some thought so watch this space.

I’ve ordered a couple of solid rear axles from China, looks like they should fit the bill nicely.
HG P401/P402/P601 1/10 RC Car Rear Gear Box HG-BX03 https://rover.ebay.com/rover/0/0/0?mpre ... 2428908500
Cheers
Wayne


Sent from my iPhone using Tapatalk

[B_Man]

That thing is huge. What were they used for?

[midlife306]

Hehe, they only built one & the Americans captured it before it could be used. It was designed to clear mines, the front wheels are a wider track than the rears to clear a wider track for the tanks, fingers crossed it should look something like this when finished...

Cheers
Wayne


Sent from my iPad using Tapatalk

[c.rainford73]

Wayne this will be such an awesome project. Will be following along with this one it's a favorite of mine

[midlife306]

Thanks, I’ve done the easy bit now, this is where it should start to get interesting, I’ve quite a few things on their way over from China & my Dremel is ready to go.
Cheers
Wayne


Sent from my iPhone using Tapatalk

[B_Man]

I'm really interested to see how you make it steer. How did the prototype do it? Was it by using the articulation joint?

[midlife306]

A lot of it is guess work, the only pics that exist only hint at he steering mechanism, all you can really see are massive hydraulic rams, these kits give a good idea though.
Think the majority of mine will be metal though as I want it to be robust.




Cheers
Wayne


Sent from my iPhone using Tapatalk

[midlife306]

After an 18 hour run, I’ve just got the first wheel off the printer, it certainly puts things in perspective!
Imagine being in a dugout & this thing is hammering towards you, I’d have my Reeboks on that’s for sure!
