British Beutepanzer Panther G

Post by LordLudikrous »

I am delighted to share the results of my latest project. I really wanted to do an M4 Sherman but was somewhat intimidated by the work I would need to do to build the sort of thing I had in mind, so I decided to do something a bit different and build a captured Panther G in British service. My particular tank is directly inspired by two real captured Panthers, Deserter and the more well known Cuckoo.



Both were early Panther Gs that fell into British hands. Deserter spent a few weeks in combat before being shipped off for testing and evaluation. It’s ultimate fate is unknown but was likely either destroyed during testing or scrapped once the war was over.

In contrast Cuckoo spent five months in service with a unit of Churchill tanks providing long range fire support. Cuckoo ultimately broke down because of a fuel pump failure, and with the crew unable to acquire a suitable replacement it was abandoned. By all accounts Cuckoo’s crew spoke highly of the tank, with particular praise directed at the 75mm Kwk 42 gun.

I envisaged the Panther being acquired in late 1944/early 1945 with a Red Oxide primer coat from the factory, as was common at the time. It’s new owners painted the hull and turret in Olive Drab with markings and livery but owing to time pressure left the running gear as it was, figuring it would not be in service for long. Later on the crew would scavenge side skirts from destroyed or abandoned Panthers in the field, giving them a hasty coat of Olive Drab when possible but leaving them in a much more deteriorated state compared to the main hull. While the side skirts would be in quite a state, weathering on the tank would be somewhat restrained, as it would be fairly new and given the lack of part supply chains would not have a long life.

This was to be a Taigen Panther G and after my positive experience installing HL 7.1 electronics in my Tiger this would use the same system. My original concept looked like this.


This is the finished result.








In addition to the 7.1 system, it has Taigen 7:1 gearboxes, a HL recoil mechanism, barrel flash and smoke and a HL J4 CNC smoker. The gunner sight has a HL IR emitter and the turret roof has a magnet in place for an IR receiver; the wiring is presently missing but will be added at a later date. The side skirts were scratchbuilt with plasticard and plastic square rods, and I added some extra detail with track retention pins made from nickel rod and access hatches for the stowage bins made from plasticard and nickel rod.

I also added some quality of life features:

• I sealed the bottom of the hull and relocated the power switch to be accessed via the radio operator hatch.
• The battery to MFU lead can be accessed via the driver’s hatch and the battery charged while inside the tank. I use Ni-Mh batteries and never charge unattended.
• The refill tube for the smoker can be accessed via the radio operator’s hatch.
• The refill port for the barrel smoker can be accessed via the commander’s cupola.
• It uses a HL slip ring which is fully compatible with Taigen turret rings.
• Under normal circumstances the tank does not need to be opened up aside for repairs or maintenance.
• The side skirts are pressure fit and can be added or removed at will.



Unfortunately it hasn’t yet had an opportunity to go play in the mud, but I’ll be sure to get some photos when it does.



User avatar
Stormbringer
Sergeant
Posts: 681
Joined: Wed Aug 06, 2025 8:24 am
Location: Near Edinburgh Scotland

Re: British Beutepanzer Panther G

Post by Stormbringer »

Really liking how this has turned out , very good job :thumbup:
Cheers
Alan

Let slip the cats of war!!!!

Taigen Panther G
Taigen T34/85
Heng Long King Tiger
Heng Long Tiger 1
Heng Long Jagdpanther
Coolbank Crusader III
User avatar
MrChef
2nd Lieutenant
Posts: 2356
Joined: Sat Jan 28, 2023 2:58 am
Location: York of New

Re: British Beutepanzer Panther G

Post by MrChef »

Very, very cool. I love it. Nicely done :thumbup:
"Charlie don't surf"- Lt. Col. Bill Kilgore
User avatar
HERMAN BIX
Major-General
Posts: 11813
Joined: Sun Jan 12, 2014 12:15 am
Location: Gold Coast,Australia

Re: British Beutepanzer Panther G

Post by HERMAN BIX »

Wonderfully narrated, even better execution!
Nice indeed to see something different.
Top job that Man
HL JAGDPANTHER,HL TIGER 1,HL PzIII MUNITIONSCHLEPPER, HL KT OCTOPUS,HL PANTHER ZU-FUSS,HL STuG III,HL T34/85 BEDSPRING,
HL PZIV MALTA,MATORRO JAGDTIGER,HL F05 TIGER,TAMIYA KT,HL PANTHERDOZER,HL EARLY PANTHER G,TAIGEN/RAMINATOR T34/76,
HL AN-BRI-RAM SU-85
User avatar
Herr Dr. Professor
Major
Posts: 5944
Joined: Mon Apr 22, 2019 10:48 pm
Location: Southern Wisconsin USA

Re: British Beutepanzer Panther G

Post by Herr Dr. Professor »

And your Booty-Tank deserves to be shown off! Yes! :thumbup: :clap: Someday if you have it open, I would be interested in seeing how you set up the charging wiring to the hatch and apparently the smoke fluid filler tube, too. I, too, use still NiMH batteries when there is enough space and LiIon batteries in tight spots. I once got to carry a burning LiPO out the door into the dirt. Quite dramatic! (No harm to me, machine, or any animals. Much laughter among the other Make Modeling Mediocre Again gang.)
LordLudikrous
Private
Posts: 96
Joined: Sun Apr 16, 2023 2:22 pm

Re: British Beutepanzer Panther G

Post by LordLudikrous »

Thanks everybody.
Herr Dr. Professor wrote: Wed Oct 29, 2025 8:35 pm And your Booty-Tank deserves to be shown off! Yes! :thumbup: :clap: Someday if you have it open, I would be interested in seeing how you set up the charging wiring to the hatch and apparently the smoke fluid filler tube, too. I, too, use still NiMH batteries when there is enough space and LiIon batteries in tight spots. I once got to carry a burning LiPO out the door into the dirt. Quite dramatic! (No harm to me, machine, or any animals. Much laughter among the other Make Modeling Mediocre Again gang.)
It's not a particularly complex arrangement.


Both are just loose under the hatches but because I went for the 7:1 gearboxes with magnetic covers it they can just go wherever without fouling anything. I just pull the wiring out the hatch, disconnect the battery from the MFU and plug it into the charger. I can also push the wiring out the way to make way for the driver figurine, it just means I sometimes have to hook my finger through the radio operator hatch to pull it back into place so I can get it out again for charging.

For me personally the risks that come with Li-Pos vastly outweigh the advantages they offer in this application, so I expect to keep using Ni-Mh for the foreseeable future.
User avatar
MrChef
2nd Lieutenant
Posts: 2356
Joined: Sat Jan 28, 2023 2:58 am
Location: York of New

Re: British Beutepanzer Panther G

Post by MrChef »

LordLudikrous wrote: Wed Oct 29, 2025 10:30 pm
It's not a particularly complex arrangement.
It's quite a nice and tidy setup :thumbup:
"Charlie don't surf"- Lt. Col. Bill Kilgore
User avatar
Herr Dr. Professor
Major
Posts: 5944
Joined: Mon Apr 22, 2019 10:48 pm
Location: Southern Wisconsin USA

Re: British Beutepanzer Panther G

Post by Herr Dr. Professor »

Thank your for the explanation and photo, LordLudrikrous. I figured it might be a relatively simple arrangement, but I long ago learned that between what "I figured" and "reality" is a great chasm. :haha: Someday I'd like to do such an arrangement and use a HengLong 7.1.
JohnWhyte
Corporal
Posts: 487
Joined: Tue Oct 04, 2016 7:20 pm
Location: Scunthorpe UK

Re: British Beutepanzer Panther G

Post by JohnWhyte »

Watching a video on the 83rd rag tag circus infantry division and there was footage of cuckoo from behind
