Jadgpanzer L70/V Build

This section is for builds that are not strictly Tamiya or Heng Long. For instance, replacing the electronics from a WSN or Matorro, or even a scratch-build.

Postby dgsselkirk » Wed Jun 04, 2014 4:24 am

Greetings Guys!

I haven't posted a build on here since my KT and I will not be going into that depth again! :haha:

So I will give basic outlines and let the pictures speak for themselves. I am no master and do not pretend to be. I try and do things the easiest, fastest, and cheapest way possible. That being said I did splurge on this one a bit. I had an HL Mk. IV that drove well but the turret set up and recoil was driving me crazy! Kept konking out and finally the elevation on the Clark board blew out so I decided to hell with it, scrap it and build an L70! So I broke down and bought from panzerparts his L70 kit for I think reasonable 109 euros. Less expensive than Profiline who we now have to wait to see their kits again. Panzerparts also comes with more metal detail pieces than resin that Profiline including a barrel which I did not use but more on that later! Here are the first hull reconstruction pics. As always I gutted the battery box and fill the lower hull with tough as steel resin. Also bought the metal drive covers with bearings from Panzerparts and they were really reasonable I thought. Mounted them and test fitted the engines and shafts...
